| Prod Model: |
MJ12-2600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Cross Cut Length: |
2600mm |
| Type: |
Table Panel Saw |
| Layout: |
Vertical |
| Controlling Mode: |
Artificial |
| Automatic Grade: |
Manual |
| Precision: |
Precision |
| Certification: |
CE |
Product Description
| 01) Motor Power:3000W(three Phases)/ 2200W(single phase) |
| 02) Major Table Size:385X800mm |
| 03) Extension Table (Cast Iron):440x800mm |
| 04) Extension Table (Steel plate):440x800mm |
| 05) Rear Extension Table:310X500mm |
| 06) Sliding panel Size:2600X270mm |
| 07) Cross Cut Table Size:680×580mm |
| 08) Cross Cut Fence:1200-2200mm |
| 09) Main Blade Size:315X30X3mm |
| 10) Main Blade Speed:4000rpm |
| 11) Scoring Blade Size:90X20X3mm |
| 12) Scoring Blade Speed:5800rpmm |
| 13) Max Cut Depth:100mm at 90 degree(315) |
| 80mm at 45 degree(315) |
| 14) Max Distance-blade to rip fence:1220mm |
| 15) Max cross cut Length: 2600mm |
| 16) Max cross Cut Width:1350mm |
| 17) Packing Size:1600x775x1040 mm |
| 2660x250x320 mm |
| 18) Weight(N,W/G,W):230/290kgs;54/66kgs |
| 19) Noise Level(Unload):85dB(A) |
| 20) Units/20'GP:14pcs |
01) Motor Power:3000W(three Phases)/ 2200W(single phase)
02) Major Table Size:385X800mm
03) Extension Table (Cast Iron):440x800mm
04) Extension Table (Steel plate):440x800mm
05) Rear Extension Table:310X500mm
06) Sliding panel Size:2600X270mm
07) Cross Cut Table Size:680×580mm
08) Cross Cut Fence:1200-2200mm
09) Main Blade Size:315X30X3mm
10) Main Blade Speed:4000rpm
11) Scoring Blade Size:90X20X3mm
12) Scoring Blade Speed:5800rpmm
13) Max Cut Depth:100mm at 90 degree(315)
80mm at 45 degree(315)
14) Max Distance-blade to rip fence:1220mm
15) Max cross cut Length: 2600mm
16) Max cross Cut Width:1350mm
17) Packing Size:1600x775x1040 mm
2660x250x320 mm
18) Weight(N,W/G,W):230/290kgs;54/66kgs
19) Noise Level(Unload):85dB(A)
20) Units/20'GP:14pcs
