Prod Model: |
MJ103-1 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Maximum Cut: |
85mm |
Motor Power: |
2, 200W, Tefc |
Blade Size: |
315 X 30 X 2.2 X 24t |
Blade Speed: |
2, 800rpm (50Hz), 3, 360rpm (60Hz) |
Table Size: |
550 X 800mm |
Table Extension: |
810mm |
Type: |
Circular Saw |
Layout: |
Horizontal |
Controlling Mode: |
Artificial |
Automatic Grade: |
Manual |
Precision: |
Precision |
Certification: |
CE |
Product Description
TECHNICAL SPECIFICATIONS:
01) Motor: 2, 200W, TEFC |
02) Blade size(mm): 315 x 30 x 2.2 x 24T |
03) Blade speed: 2, 800rpm (50Hz), 3, 360rpm (60Hz) |
04) Table size: 550 x 800mm |
05) Table extension: 810mm |
06) Maximum cut at 45/90 degree: 60/85mm |
07) Working height: 800mm |
08) Lenght of rip fence: 580mm |
09) Net/gross weight: 45/48kg |
10) Packing size: 850 x 600 x 430mm |
11) Units per 20-foot container: 120 |
01) Motor: 2, 200W, TEFC
02) Blade size(mm): 315 x 30 x 2.2 x 24T
03) Blade speed: 2, 800rpm (50Hz), 3, 360rpm (60Hz)
04) Table size: 550 x 800mm
05) Table extension: 810mm
06) Maximum cut at 45/90 degree: 60/85mm
07) Working height: 800mm
08) Lenght of rip fence: 580mm
09) Net/gross weight: 45/48kg
10) Packing size: 850 x 600 x 430mm
11) Units per 20-foot container: 120
