Prod Model: |
MJ12-1360E |
Major Table Size: |
350X760 mm |
Extension Table: |
600X760mm |
Sliding Panel Size: |
1360X270mm |
Type: |
Table Panel Saw |
Layout: |
Horizontal |
Controlling Mode: |
Artificial |
Automatic Grade: |
Manual |
Precision: |
Precision |
Certification: |
CE |
Product Description
01) Motor Power: 2200W(brake motor) |
02) Major Table Size:350X760 mm |
03) Extension Table (Steel plate):600x760mm |
04) Rear Extension Table:350X500mm |
05) Sliding panel Size:1360X270mm |
06) Cross Cut Table Size:680×580mm |
07) Cross Cut Fence:1200-2200mm |
08) Blade Size:315X30X3mm |
09) Blade Speed:4250rpm(50hz),5130rpm(60hz) |
10) Max Cut Depth:100mm at 90 degree(315) |
11) Max Cut Depth:75mm at 45 degree(315) |
12) Cutting width on rip fence:940mm |
13) Cutting Length: 1220mm |
14) Packing Size: (1)1000X950X1000mm,2)1450X500X160mm |
15) Weight(N,W/G,W):194kg/254kg |
16) Units/20'GP:20pcs |
01) Motor Power: 2200W(brake motor)
02) Major Table Size:350X760 mm
03) Extension Table (Steel plate):600x760mm
04) Rear Extension Table:350X500mm
05) Sliding panel Size:1360X270mm
06) Cross Cut Table Size:680×580mm
07) Cross Cut Fence:1200-2200mm
08) Blade Size:315X30X3mm
09) Blade Speed:4250rpm(50hz),5130rpm(60hz)
10) Max Cut Depth:100mm at 90 degree(315)
11) Max Cut Depth:75mm at 45 degree(315)
12) Cutting width on rip fence:940mm
13) Cutting Length: 1220mm
14) Packing Size: (1)1000X950X1000mm,2)1450X500X160mm
15) Weight(N,W/G,W):194kg/254kg
16) Units/20'GP:20pcs
