Prod Model: |
MJ12-1600E |
Major Table Size: |
350X760mm |
Extension Table: |
600X760mm |
Rear Extension Table: |
350X500mm |
Sliding Panel Size: |
1600X238mm |
Type: |
Table Panel Saw |
Layout: |
Vertical |
Controlling Mode: |
Artificial |
Automatic Grade: |
Manual |
Precision: |
Precision |
Certification: |
CE |
Product Description
01) Motor Power: 2200W(brake motor) |
02) Major Table Size: 350X760mm |
03) Extension Table (Steel plate): 600x760mm |
04) Rear Extension Table: 350X500mm |
05) Sliding panel Size: 1600X238mm |
06) Main Blade Size: 315X?30X3mm |
07) Main Blade Speed: 4250rpm |
08) Max Cut Depth: 105mm/ 90°; 75mm /45° |
09) Max Distance-blade to rip fence: 940mm |
10) Max cross cut Length: 1450mm |
11) Max cross Cut Width: 940mm |
12) Net / Gross Weight : 170/235kg 32/35kg |
13) Packing Dimensions: 1220X1002X1026mm / 1770X450X200mm |
14) Units/20'GP:20pcs |
01) Motor Power: 2200W(brake motor)
02) Major Table Size: 350X760mm
03) Extension Table (Steel plate): 600x760mm
04) Rear Extension Table: 350X500mm
05) Sliding panel Size: 1600X238mm
06) Main Blade Size: 315X?30X3mm
07) Main Blade Speed: 4250rpm
08) Max Cut Depth: 105mm/ 90°; 75mm /45°
09) Max Distance-blade to rip fence: 940mm
10) Max cross cut Length: 1450mm
11) Max cross Cut Width: 940mm
12) Net / Gross Weight : 170/235kg 32/35kg
13) Packing Dimensions: 1220X1002X1026mm / 1770X450X200mm
14) Units/20'GP:20pcs
