2.7mm Galvanized Gabion Box/Gabion Mesh Box/Gabion Boxes & Gabion Mattress (Peaceful)

Prod Model:	HP-105
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mesh Opening:	60mm X 80mm,80mm X 100mm,100mm X 120mm
Galvanized Wire:	2.2mm,2.7mm,3.0mm
PVC Coated Wire:	2.2/3.2mm , 2.7/3.7mm , 3.0/4.0mm
Gabion Box Size:	1X1X1m , 1.5X1X1m, 2X1X1m,etc
Material:	Galvanized Iron Wire
Application:	Construction Wire Mesh
Hole Shape:	Hexagonal
Usage:	Civil Engineering
Technics:	Woven
Aperture:	80*100mm
Surface Treatment:	Hot-Dipped Galvanized or PVC Coated
Size:	1m 1m X 1m ,2m X 1m X 0.5m , 2m X 1m X 1m

Product Description

Introductions of gabion

1. Material: Hot-dipped galvanized wire (Zinc coating : 250-300/m2), PVC-coated wire, Galfan coated wire (95% Zinc 5% Aluminum for up to 4 times the life of a galvanized finish)
2.details specification for gabion
Gabion mesh wire: 2.0mm, 2.4mm, 2.7mm, 3.2mm, 3.4mm, 4.0mm.

Gabion selvedge wire diameter: 2.4mm, 2.7mm, 3mm, 3.4mm, 4.0mm.
Hole size: 60x80mm,80x100mm,100x120mm,120x150mm, etc.
Gabion Tie wire/lacing wire : 2.2mm, 3% or 5% of total weight

Gabion size: 1x1x1m, 1.5x1x1m,2x1x1m, 2x1x0.5m, 3x1x1m, 4x1x1m, as your request
Diaphragm: 1 diaphram per meter.

3.Uesage: The stone cage nets widely used to control and guide the rivers and flood diversion, flood dam, rockfall fine protective, to prevent soil erosion,protect bridge, protect coastal defense engineering, port engineering, retaining wall, road protection.


Mesh Size(mm)	No. Of Diaphragm	Approximate Dimensions and volumes				Tolerance	Color (PVC coated wire)	Wire
		Length	Width	Depth	Capacity
60x80 80x100 80x120 90x110 100x120 110x130 120x150	1	2.0m	1.0m	0.5m	1.0m	L+/-3% W+/-5% H+/-5%	Silver Bright Dark Green Gray Black (Moss green)	Hot dipped galvanized, PVC Coated, galfan coated, wire Diameter: 2.0, 2.2, 2.4, 2.7, 3.0mm
	1	2.0m	1.0m	1.0m	2.0m
	2	3.0m	1.0m	0.5m	1.5m
	2	3.0m	1.0m	1.0m	3.0m
	3	4.0m	1.0m	0.5m	2.0m
	3	4.0m	1.0m	1.0m	4.0m
	1	2.0m	0.5m	0.5m	0.5m
	2	3.0m	0.5m	0.5m	0.75m
	4	5.0m	1.0m	0.5m	2.5m
	4	5.0m	1.0m	1.0m	5.0m
	5	6.0m	1.0m	1.0m	6.0m

Applicantion:
1) Channel Linking and Flood Protection
2) Build Sluice Dam and Headrace Dam
3) Rock-fall and Landslide Protection
4) Bridge Protection
5) Soil Retention
6) Costline Structure and Protection
7) Haven Works
8) Retaining Walls
9) Roadway Protection

In gerneral speaking , some specifications , we could be according to customer's request arrange for production , if you need any details informations , please just be contact us .
