40kg Power Pneumatic Air Forging Hammer with CE Approved (C41-40)

Name: 40kg Power Pneumatic Air Forging Hammer with CE Approved (C41-40)
Brand: tool-buy.com
SKU: 760370145
Availability: InStock
Rating: 4.5 (58 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Zaozhuang Make Machinery Co., Ltd.

Showroom Product Company Profile

Prod Model:	C41-40
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	C41-40,C41-55,C41-75,C41-150
Forging Forming Method:	Mold Forging

Product Description

C41-40 Air Forging Hammer with CE Approved
Main Features

The air hammer with small size,low noise,simple structure ,
easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawingout ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for opendie forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and selfemployed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.

Specifications
1.Durable and great power
2.Easy installation and operation
3.Convenient maintenance
4.Professional hammer die upon your need

SPECIFICATION	UNIT	C41-40kg	C41-55kg	C41-75kg	C41-150kg
SPECIFICATION	UNIT	separate/single	separate	separate	separate
Max. hit energy	kj	0.53	0.7	1	2.2
Height of working area	mm	245	265	300	370
Hit number	min -1	245	230	210	180
Dimension of top and bottom die surface(LxW)	mm	120*50	120*55	145*65	200*85
Max. square steel can be forged	mm	52*52	52*52	65*65	130*130
Max. round steel can be forged(Diameter)	mm	¢68	¢68	¢85	¢145
Motor power	kw	4	5.5	7.5	15
Speeds of motor	r. p. m	1440	1440	1440	1470
Anvil weight	kg	400/0	600	850	1800
Total weight	kg	1350/880	1700	2800	5060
Overall dimensions(LWH)	mm	10806001430	13206701620	14007601950	208012402350

Brief introduction

Zaozhuang Make Machinery Co., Ltd., located at Zaozhuang city Shandong province, which is the midway between Beijing and Shanghai, closed to Qingdao port, has been focusing on manufacturing machine tools for more than 20 years. This is an integrated manufacturing company which includes design, machining, assembly, installation, commissioning and after-sales service. With a long time experience in exporting machines, we are specialized in servicing international customers, and in particular, familiar with the quality standards from different countries. This enables us to supply our customers consistent high-quality products, as well as providing excellent customer services. Zaozhuang Make Machinery Co., Ltd. Is your ideal cooperative partner, with our continuing growth through dedicating ourselves to growth of our customers.

Strength

1. Dealing directly with the manufacture-----no middle man

2. The most competitive pricing in the market.

3. High-quality control standards, such as ISO, CE

4. Prompt attention to customer inquiries.

5. Diverse services for your needs, including sourcing other machinery and purchasing them as your agent, inspection goods for you by our engineers, the spare parts distribution, quality modifying, product process tracking and good delivery. The feedback to you will be within 24 hours.

6. Research and development to meet needs of customers and the market.

Product range

1. Plano miller: Series CNC Plano Miller, Series Plano Milling Machine, Series Gantry Milling Machine, Series Planer Milling machine

2. Series Guideway Grinding machine

3. CNC machine center

4. Series Conventional Milling Machine & Milling/ Drilling Machine

5. Drilling machine: Series CNC Drilling Machine, Series Radial Drilling Machine, Series Vertical Drilling Machine

6. Lathe: Series CNC Lathe, CNC Lathe-Inclined bed type

7. Hydraulic Press: Series Gantry Hydraulic Press, Series C-Type Hydraulic press, Series Hydraulic Bend

8. Garage equipment: Series Cylinder Boring Machine, Cylinder Honing machines, Series Brake Drum Boring Machine, Brake Lathe,

Brake Drum (Disc) Cutting Machine

9. Riveting Machine: Series Hydraulic Riveting Machine & Pneumatic Riveting Machine

10. Light Slotting Machine & Slotting Head

11. Bench Grinder & Vertical Grinding Machine

12. Series Arbor press

13. Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal boring head, Clamp kits, etc.

Research and Development

Our products are based on research and development to ensure needs of customers and the changing market.

Quality Control

Quality control is the key principle for Zaozhuang Make Machinery Co., Ltd. Our manufacturing has adopted modernized ISO Quality Management Systems, sound operational procedures as well as effective product and customer service system.

These systems ensure all products produced under very strict quality control, maintaining our high standards to ensure your ongoing success by using our products.

Quality guarantee period

We guarantee all our products to be defect free for one year from the date of purchase. Our after-sales service will cover any issue that may occur promptly.

Customer service

We have professional technicians to provide ongoing support for customers, during and after the guarantee period. We will attend your requests including large-type CNC machine tools installation and adjustment.

Special order

With our extensive experience in this industry, we are in the best position to meet needs of our customers, for both normal standard commodities and special orders. We guarantee to have the best price for your product based upon your detail requirements.

YOUR GOAL, OUR GOAL.
