| Prod Model: |
chain link fence |
| Mesh Size: |
50mm X 50mm |
| Wire Thickness: |
1.6mm-4.0mm |
| Material(1): |
Glavanized and PVC Coated Wire |
| Material(2): |
Hot Dipped Galvanized Wire |
| Post Size: |
60mm, 76mm |
| Rail Size: |
48mm |
| Straining Post: |
60mm, 76mm |
| Support Post: |
60mm, 76mm |
| Barbed Arm: |
Single or Double |
| Barbed Wire: |
Double Twist, Four Point |
| Material: |
Galvanized Iron Wire |
| Application: |
Construction Wire Mesh |
| Hole Shape: |
Diamond |
| Surface Treatment: |
Galvanized |
| Weave Technique: |
Chain Link |
Product Description
Chain link panel with Concertina razor wire on top for airport
The Chain Link Fence is made of woven steel wire, which is one of the most commonly used and versatile of all the fencing fabrics. It is normally available in a variety of wire gauges and mesh sizes to suit individual applications. All chain link rolls come complete with line wires and with knuckled edges. Barbed (protruding) edges increase the security of the fencing and are available to order. Airport fence, by definition is mainly used in the airport as a protective fence.The net body is welded with 4.0/5.0mm low carbon steel wire , the surface will be electrostatic polyester powder coated or PVC coated afterelectro-galvanized. 60 mm Y shaped square pipe will be put at 2.5m intervals for the connection of the mesh.Concertina wire will be put at the top of the fence to make the fence more securer.
Mesh Panel
Panel | Mesh | Wire Thickness | Surface Treatment | Panel Width | Folds NOS. | Panel
Height | Fence Height |
Big Panel | 50x100mm
55x100mm | 4.00mm
4.50mm
5.00mm | Galvanized and
Electrostatic polyester coated or PVC coated | 2.50m
3.00m | 4 | 2000mm | 2700mm |
5 | 2300mm | 3200mm |
6 | 2600mm | 3700mm |
2 | 530mm | 2700mm |
V panel | 630mm | 3200mm |
730mm | 3700mm |
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
60x60mm | 2.0mm
2.5mm | Galvanized and
Electrostatic polyester powder coated | 2700mm I
+
530mm V | Available
On request | Plastic or Metal |
3100mm I
+
630mm V |
3600mm I
+
730mm V |
Support Post
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
60x60mm | 2.0mm
2.5mm | Galvanized and
Electrostatic polyester powder coated | 1900mm /
+
400mm I | Available
On request | Plastic or Metal |
2200mm /
+
500mm I |
2500mm /
+
500mm I |
Hebei Qianye Metal Product Co., Ltd is a company engaged in production and exportation of metal fence as well as other metal products. Its registered capital is RMB50, 100, 000(about USD7, 400, 000), covering a land area of 30, 000 square meters.
Since its foundation in 2002, this company has been always adhering to the principle of uncompromising integrity and credibility first in doing things. We making our own Brand QYM and has been exporting the QYM-Welded Mesh Fence, QYM-Airport Fence, QYM-High Security Fence, QYM-Palisade Fence and other high grade protective fences to over 100 countries and regions in Europe, America, Africa, Middle East and Australia. In 2008, our export of 120 km metal fence to America made us an apparent leader in the local fence industry; In 2009, we successfully took and completed the orders from UN which perfectly proved our good reputation and our strong production capability.
Through years of production experience, we deeply understand that the qualified product is the factory basis for survival and development. In order to ensure consistency of product quality, our company introduced a fully automatic panel fence welding equipment, automatic electrostatic spraying production line, as well as advanced welding machines, cutting machines, punching machines and bending machines. We have first-class product design department responsible for new product reserch, first-class quality control department responsible for timely monitoring of product at each production process and first-class one-to-one sales staff to provide you with efficient services.
