Prod Model: |
C41-55 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
C41-40,C41-55,C41-75,C41-150 |
Forging Forming Method: |
Mold Forging |
Product Description
C41-55 55kg Power Die Air Forging Hammer with CE Approved
Main Features
The air hammer with small size,low noise,simple structure ,
easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawingout ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for opendie forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and selfemployed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.
Specifications
1.Durable and great power
2.Easy installation and operation
3.Convenient maintenance
4.Professional hammer die upon your need
SPECIFICATION | UNIT | C41-40kg | C41-55kg | C41-75kg | C41-150kg |
separate/single | separate | separate | separate |
Max. hit energy | kj | 0.53 | 0.7 | 1 | 2.2 |
Height of working area | mm | 245 | 265 | 300 | 370 |
Hit number | min -1 | 245 | 230 | 210 | 180 |
Dimension of top and bottom die surface(LxW) | mm | 120*50 | 120*55 | 145*65 | 200*85 |
Max. square steel can be forged | mm | 52*52 | 52*52 | 65*65 | 130*130 |
Max. round steel can be forged(Diameter) | mm | ¢68 | ¢68 | ¢85 | ¢145 |
Motor power | kw | 4 | 5.5 | 7.5 | 15 |
Speeds of motor | r. p. m | 1440 | 1440 | 1440 | 1470 |
Anvil weight | kg | 400/0 | 600 | 850 | 1800 |
Total weight | kg | 1350/880 | 1700 | 2800 | 5060 |
Overall dimensions(L*W*H) | mm | 1080*600*1430 | 1320*670*1620 | 1400*760*1950 | 2080*1240*2350 |
