Prod Model: |
C41-20 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Max Hit Force: |
0.22kg |
Hit Frequency: |
255 Times/Min |
Speed Of Motor: |
1440rpm |
Overal Dimension: |
1290X520X1560mm |
Forging Forming Method: |
Mold Forging |
Product Description
No base
With base
C41-20KG Products air power forging hammer
Main Features
The air hammer with small size,low noise,simple structure ,
easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawingout ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for opendie forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and selfemployed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.
Specifications
1.Durable and great power
2.Easy installation and operation
3.Convenient maintenance
4.Professional hammer die upon your need
SPECIFICATION | UNIT | C41-20(Integrated) | C41-20 (Separated) |
Max. hit force | kj | 0.22 |
Height of working area | mm | 200 |
Hit frequency | times/min | 255 |
Dimension of top & bottom die surface(L*W) | mm | 90*50 |
Max. square steel can be forged | mm | 30*30 |
Max. round steel can be forged(Diameter) | mm | 35 |
Motor power | kw | 2.2 |
Speeds of Motor | r.p.m | 1440 |
Anvil weight | kg | | 190 |
Total weight(N.W/G.W) | kg | 380/440 | 500/560 |
Overall dimensions(L*W*H) | mm | 820*460*1110 | 820*460*1110 |
