| Prod Model: |
Omp160 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Displacement(Cc/Rev): |
160 |
| Continuous Max Speed(Rpm): |
383 |
| Continuous Max Torque(N.M): |
302 |
| Hole Middle Distance: |
106.4mm |
| Cylinde Parallel Shaft Size: |
25mm |
| Flange: |
Standard 2 Hole Diamond Flange |
| Max Pressure(Bar/MPa): |
140/14 |
| Ports And Drain Port: |
G1/2, G1/4 |
| Material: |
Rust-Proof Cast Iron |
| Warranty: |
One Year |
| Hydraulic Power Units: |
Gear Pump |
| Hydraulic Valve: |
Hydraulic Motor |
| Auxiliary Components: |
Hydraulic Motor |
| Hydraulic Fluid: |
Hydraulic Motor |
| Flow Control Valve: |
Hydraulic Motor |
| Pressure Control Valve: |
Orbital Motor |
| Hydraulic Control Unit: |
Hydraulic Motor |
| Hydraulic Motor: |
Omp Hydraulic Motor |
| Hydraulic Actuator: |
Hydraulic Motor |
Product Description
Blince Hydro motors OMP160 Series is Popular Applied In:
-Winch in boat -Plastic Injection Moulding Machine -sweeper machine
- lawn mower -road line marker-wheat harvest machine and other light machinery-car tail lift
Typical feature
1. High pressurre of shaft seal
3. Phosphating coating to protect from rusting
2. Freely disassemble leakage ports
4. Needle bearing
5. Omp500 be Compatible With M+S MR/MLHR
| type | OMP
OMPH
36 | OMP
OMPH
50 | OMP
OMPH
80 | OMP
OMPH
100 | OMP
OMPH
125 | OMP
OMPH
160 | OMP
OMPH
200 | OMP
OMPH
250 | OMP
OMPH
315 | OMP
OMPH
400 | OMP
OMPH
500 |
| Geometric displacement | 36 | 51.7 | 77.7 | 96.2 | 120.2 | 157.2 | 194.5 | 240.3 | 314.5 | 389.5 | 486.5 |
| Max.speed.(rpm) | con. | 1500 | 1150 | 770 | 615 | 490 | 383 | 310 | 250 | 192 | 155 | 120 |
| int. | 1650 | 1450 | 960 | 770 | 615 | 475 | 385 | 310 | 240 | 190 | 150 |
| Max.torque(N.m | cont. | 55 | 100 | 146 | 182 | 236 | 302 | 360 | 383 | 375 | 360 | 385 |
| int. | 76 | 128 | 186 | 227 | 290 | 370 | 440 | 460 | 555 | 525 | 560 |
| Max.output(KW) | cont. | 8.0 | 10.0 | 10.0 | 11.0 | 10.0 | 10.0 | 10.0 | 8.5 | 7.0 | 6.0 | 5.0 |
| int | 11.5 | 12.0 | 12.0 | 13.0 | 12.0 | 12.0 | 12.0 | 10.5 | 8.5 | 7.0 | 6.0 |
Max.pressure
Drop(Mpa) | cont. | 12.5 | 14 | 14 | 14 | 14 | 14 | 14 | 11 | 9 | 7 | 6 |
| int | 16.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 14 | 10.5 | 9 |
| Max.flow(L/min) | cont. | 55 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 |
| OMP50-2AD (OMP-1510310) | OMP50-2AD (OMP-1510610) |
| OMP50-2CD (OMP-1510300) | OMP50-2CD (OMP-1510600) |
| OMPH50-H2RS (OMP-1517041) | OMP50-2ED (OMP-1510330) |
| OMP50-2ED (OMP-1510630) | OMP50-4BD (OMP-1515001) |
Blince manufactured factory estblish in 2004s , we are full experience to technical adis for hydraulic motor omr /omrs/omm /omp/omph/omt/omv/oms/omsy/ok/oz/ 6kseries & vane pump( PV2R, VQ ,V ,SQP Series.pump cartridge)
We own ourself brand in 2010 years "blince" ,to enlarge name plate efforts ,also support customization
Our order track information " & perfomance certificate . please entre in the "company profile part " to seek
If you have any requests, to get from us! ! I am so glad to provide our best services
Contact detail as follows
Jamse Chen
Tel: 86-0769-85156586
Phone:86-18707812826
Fax: 86-0769-85150786
Established in 2004, Dongguan Blince Machinery & Electronics Co., Ltd. Specializes in the business of hydraulic motor, cycloid m...MoreEstablished in 2004, Dongguan Blince Machinery & Electronics Co., Ltd. Specializes in the business of hydraulic motor, cycloid motor, vane pump and hydraulic valve. Located in Changan, Dongguan, Guangdong, we enjoy convenient access to major transportation networks. Our company covers an area of 30, 000 square meters and has around 361 people staff members. Furthermore, all our products are manufactured with advanced equipment and strict QC procedures in order to ensure high quality. With stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.
Blince main product is orbit motor like (OMM/OMP/OMR/OMH/OMT/OMS/OMV), Radial Piston Motor(NHM 1/2/3/6/8/11/16/31), hydraulic pump (PV2R series, V/VQ series, SQP series) valve and a set of hydraulic system.
Our product widely application for fishing machinery, agricultural machinery, engineering machinery, mining machinery, industrial machinery, aviation and transport machinery et
Blince hydraulic motor Can perfect replace:
Danfoss: OMM/OMP/OZ/OMR/OK/OMH/OMS/OMT/OMV orbital motor
Eaton: J (129-) series, H(101-) series, S(103-) series, T(158-)series, 2000(104-) series, 6000 series orbit motor
White: MP/RS/MR/RG/HB/CE/RE series hydraulic motor
Parker: TE and TG series hydraulic motor
