Orbit Omm12.5 Hydraulic Motor 1500rpm for Fishing Net Machine

Prod Model:	OMM 12.5 hydraulic motor
Max. Speed(Cont.):	1550rpm
Fuel:	Hydraulic Oil
Material:	Cast Iron
Shaft Type:	Parallel Key/ Involute Key Shaft
Port Type:	Side Port/End Port
Structure:	Shaft Distribution Flow
Application:	Medium and Low Duty Tasks
Place Of Origin:	Guangdong, China (Mainland)
Stock:	Rich
Weight:	2kg

Product Description


BLINCE OMM series motor are small volume, economical type, which is designed with shaft distribution flow, which adapt the Gerotor gear set design and provide compact volume, high power and low weigth.

Characteristic features:
* Advanced manufacturing devices for the Gerotor gear set, which provide small volume, high efficiency and long life.
* Shaft seal can bear high pressure of motor of which can be used in parallel or in series.
* Advanced construction design, high power and low weight.

The Model Parameters of OMM Hydraulic Motors:
*Displacement: 8 / 12.5 / 20 / 32 / 40 / 50
*Flange: 3-M6 Circle-flange, pilotØ 31.5× 5
3-1/4-28UNF Circle flange, pilot Ø 31.5× 5
2-Ø 9 Rhomb-flange, pilotØ 63× 2
*Output shaft: ShaftØ 16, parallel key 5× 5× 16
ShaftØ 15.875, parallel key 4.8× 4.8× 19.05
ShaftØ 16.5, involute B17× 14, DIN5482
*Ports and drain port: G3/8, G1/8
9/16-18UNF, 3/8-24UNF
End port G3/8, G1/8
End port 9/16-18UNF, 3/8-24UNF
*Rotation direction: Forward&Reverse
*Paint: No paint / Silver grey / Black / Blue

Our Blince OMM series motor used in the following application areas:
* Construction equipment
* Agricultural equipment
* Material handling & Lifting equipment
* Forestry equipment
* Lawn and turf equipment
* Special purpose
* Machine tools and stationary equipment
* Marine equipment
* Any More

BLINCE OMM HYDRAULIC MOTOR CAN SUBSTITUE FOR:
* Sauer Danfoss OMM series
* White Drive Product WP/155 Series
* White Drive Product WG/275/277/280 Series
* M+S Motor MP/MLHP Series
* Brewin Motor BG Series
* Japan OPN ORB-GS Series
* Any More

WHY US:
1. We are leading profesional manufacturer of Hydraulic motor in Guangdong China. Our products have been exported to more than 50 countries including Africa, Middle East, South America and Asia.
2. We are not only produce normal models, but also produce new models according to your design.
3. Professional service team and competitive price will give you a perfect purchasing experience.

Warranty:
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems
Caused by our quality of production or raw material.
3. My dear friend, your emails can be get within one business day. If you do not receive our reply, please kindly re-sent your email or give us a call any time.

If you have any questions or other hydraulics informations what I can do for you. Please contact me directly or visit our website. The best service you will get soon! : )

Landy Huang
Cell:008613558032097

Main Specification
Blince OMM orbital hydraulic motors which can help you as following:

Type		OMM  8	OMM  12.5	OMM  20	OMM  32	OMM  40	OMM  50
Geometric displacement (cm³/rev.)		8.2	12.9	19.9	31.6	39.8	50.3
Max.speed (rpm)	cont.	1950	1550	1000	630	500	400
	int.	2450	1940	1250	800	630	500
Max. torque  (N?m)	cont.	11	16	25	40	45	46
	int.	15	23	35	57	70	88
	peak	21	33	51	64	82	100
Max.output  (kW)	cont.	1.8	2.4	2.4	2.4	2.2	1.8
	int.	2.6	3.2	3.2	3.2	3.2	3.2
Max. pressure  drop  (MPa)	cont.	10	10	10	10	9	7
	int.	14	14	14	14	14	14
	Peak	20	20	20	16	16	16
Max. flow (L/min)	cont.	16	20	20	20	20	20
	int.	20	25	25	25	25	25
Max.inlet pressure (MPa)	cont.	17.5
	int.	22.5
Net Weight  (kg)		1.9	2	2.1	2.2	2.3	2.4
