| Price: | US $ 3690-12400/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | SJY0.5-08 |
|---|---|
| Material: | High-Duty Steel Structure |
| Platform: | Antiskid Platform |
| Control Mode: | Electric Box and Button |
| Tire: | Four Pneumatic Tires |
| Color: | Blue, Red, Ect |
| Usage: | Workshop, Square, Gas Station, Ect |
| Hydraulic Cyclinder: | 2-4 |
| Voltage: | 110V 220V 240V 380V Optional |
| Max Heigh: | 16m |
| Min Heigh: | 4m |
| Application: | Building Crane |
| Carrying Capacity: | Weight Level |
| Driven Type: | Hydraulic |
| Running Mode: | Moving |
| Feature: | Explosion-Proof |
| CE ISO passed hydraulic power unit auto lift for installing | |
| basic parameter | |
| 1. Load capacity: 300-2000kg 2. Lifting height: 4-16m 3. Drive power: 4 pneumatic rubber tyres. 4. Applications: aerial installation, maintenance, clean at the construction sites, workshops, warehouse, station, hotel, airport, wharf, gas station and stadium etc. 5. Custom-made according to the requirement | |
| The safety protection | |
| 1. Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture 2. Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure. 3. Emergency decline valve: it can go down when you meet an emergency. | |
| The features | |
| 1. The equipment is mainly used to lift workers to higher places for maintenance, cleaning or installation. 2. An ideal equipment of safe operation 3. It is characterized by great loading capacity. | 4. Steady ascending and descending 5. Mobile convenient, easy to work. 6. Local voltage can be customerized (380V/400V/415V/110V/220V) 7.Control way: electric box/button |
| Model | Lifting height (M) | Loading capacity (KG) | Table size (L*W )(MM) | Total dimension (L*W*H)(MM) | Power (KW) | Weight (KG) |
| SJY0.3-4 | 4 | 300-2000 | 1750*1100 | 1800*1300*1350 | 3 | 660 |
| SJY0.3-6 | 6 | 300-2000 | 1750*1100 | 1800*1300*1350 | 3 | 750 |
| SJY0.3-8 | 8 | 300-2000 | 1750*1100 | 1800*1300*1550 | 3 | 1000 |
| SJY0.3-10 | 10 | 300-1000 | 2000*1300 | 2700*1550*2380 | 3 | 1400 |
| SJY0.5-10 | 10 | 500-2000 | 2000*1300 | 2050*1400*1860 | 3 | 1800 |
| SJY0.3-12 | 12 | 300-500 | 2000*1300 | 2550*1630*2000 | 3 | 2000 |
| SJY0.3-14 | 14 | 300-1000 | 2400*1500 | 2550*1630*2000 | 3 | 2400 |
| SJY0.3-16 | 16 | 300-1000 | 2700*1500 | 2770*1630*2140 | 3 | 2800 |
| To satisfy your needs is always our first job.Since your first purchase,training,parts,maintenance and repair everything are included | |
| 1.Presale service: | we could be your personal service team,call us any time you facing problem. |
| 2.In sale service: | Professional guidance from our genius enjineer will let you know more about your equipment,both machine control and inside mechanism. |
| 3.After-sale service: | One year warranty service of whole machine and lifetime maintenance.our service team will provide you full service,inspection,repair,maintainance to improve performance and extend life cycle. |
