| Prod Model: |
G-213 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
7/8 |
| Weight: |
3.28 Lbs |
| Wll: |
6-1/2 Ton |
| Material: |
Steel |
Product Description
Name: HDG Us Type Drop Forged Lifting Shackle
Item Number: G-213
Size : 7/8
Material: Carbon Steel 45#
Weight Each: 3.28lbs.
WLL: 6-1/2 ton
FOS: 5:1
Note:
Working load limit permanently shown on every shackle.
Forged, Quenched and Tempered, with alloy pins.
Hot Dip Galvanized, Zinc Plated or Self-colored
Prood load is two times the working load limit.
Ultimate load is 5 times the working load limit.
| G-213/S-213 ROUND PIN SHACKLE |
| Nominal Size | Working Load Limit | Weight Each | Dimensions(mm) | |
| (in.) | (tons) | (kg) | A | B | C | D | E | F | G | H | N | P |
| 1/4 | 1/2 | 0.05 | 11.90 | 7.85 | 28.70 | 6.35 | 19.80 | 15.50 | 32.50 | 46.70 | 34.0 | 6.35 |
| 5/16 | 3/4 | 0.09 | 13.50 | 9.65 | 31.00 | 7.85 | 21.30 | 19.10 | 37.30 | 53.00 | 40.4 | 7.85 |
| 3/8 | 1 | 0.14 | 16.80 | 11.20 | 36.60 | 9.65 | 26.20 | 23.10 | 45.20 | 63.00 | 47.2 | 9.65 |
| 7/16 | 1-1/2 | 0.17 | 19.10 | 12.70 | 42.90 | 11.20 | 29.50 | 26.90 | 51.50 | 74.00 | 54.1 | 11.20 |
| 1/2 | 2 | 0.33 | 20.60 | 16.00 | 47.80 | 12.70 | 33.30 | 30.20 | 58.50 | 83.50 | 60.5 | 12.70 |
| 5/8 | 3-1/4 | 0.62 | 26.90 | 19.10 | 60.50 | 16.00 | 42.90 | 38.10 | 74.50 | 106.00 | 73.9 | 17.50 |
| 3/4 | 4-3/4 | 1.07 | 31.80 | 22.40 | 71.50 | 19.10 | 51.00 | 46.00 | 89.00 | 126.00 | 87.4 | 20.60 |
| 7/8 | 6-1/2 | 1.64 | 36.60 | 25.40 | 84.00 | 22.40 | 58.00 | 53.00 | 102.00 | 148.00 | 96.8 | 24.60 |
| 1 | 8-1/2 | 2.28 | 42.90 | 28.70 | 95.50 | 25.40 | 68.50 | 60.50 | 119.00 | 167.00 | 115.1 | 26.90 |
| 1-1/8 | 9-1/2 | 3.36 | 46.00 | 31.80 | 108.00 | 29.50 | 74.00 | 68.50 | 131.00 | 190.00 | 130.3 | 31.80 |
| 1-1/4 | 12 | 4.31 | 51.50 | 35.10 | 119.00 | 32.80 | 92.50 | 76.00 | 146.00 | 210.00 | 139.7 | 35.10 |
| 1-3/8 | 13-1/2 | 6.14 | 57.00 | 38.10 | 133.00 | 36.10 | 92.00 | 84.00 | 162.00 | 233.00 | 155.7 | 38.10 |
| 1-1/2 | 17 | 7.8 | 60.50 | 41.40 | 146.00 | 39.10 | 98.50 | 92.00 | 175.00 | 254.00 | 165.1 | 41.10 |
| 1-3/4 | 25 | 12.6 | 73.00 | 51.00 | 178.00 | 46.70 | 127.00 | 106.00 | 225.00 | 313.00 | 196.9 | 57.00 |
| 2 | 35 | 20.4 | 82.50 | 57.00 | 197.00 | 53.00 | 146.00 | 122.00 | 253.00 | 348.00 | 222.3 | 61.00 |
| 2-1/2 | 55 | 38.9 | 105.00 | 70.00 | 267.00 | 69.00 | 184.00 | 145.00 | 327.00 | 453.00 | | 79.50 |
About Us
--------------------------------------------------------
Our company is mainly engaged in the R&D, manufacture and sale of rigging products. We focus on the production of rigging for more than two decades. Our main product portfolios include turnbuckles, eye bolts, shackles, wire rope clips, thimbles, hooks and swivels, earth anchors, wire rope accessories. We can also customize rigging products as per drawings, samples and the relevant technical requirements that customers may provide us with.
ROY RIGGING is dedicated to ensure quality of raw material and make sure every step of production process to be strictly controlled, our company has obtained many certificates including ISO, SGS, CE, BV. Our well-trained technical and professional staffs have rich expertise and experience in rigging hardware industry.
Based on the principle of mutual cooperation and mutual development, we sincerely look forward to entering into business cooperation with more customers around the world.
Our Advantages
--------------------------------------------------------------------
We are a real factory, rather than a trading company.
Our factory owns BV, SGS Field certification and ISO quality management system certification.
With more than two decades of production experience in terms of rigging hardware products, all inquiries will be responded within 12 hours.
Our products have been exported to over 50 countries, factory test certificate can be provided as request.
No MOQ limit, punctual delivery, excellent quality, competitive price and efficient sale service.
Be good at Custom-made and Shaped product.
100% Finished Product Testing.
Inspection before loading.
