High Speed Lab Diamond Cut-off Saw
| Price: |
US $ 600-720/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
CY-SYJ-40 |
| Voltage: |
110/ 220V |
Product Description
CY-SYJ-40 Diamond Cut-off Saw with Vise and Diamond Blades
CY-SYJ-40 is a 4" manual cut-off saw and the perfect tool for cutting valuable materials quickly, such as rough crystal, ceramic, metal rod and almost any material before lapping and polishing.
Specification
Voltage: AC 110/ 220V, 50/ 60Hz
Motor and Spindle:
1) The 1/4 HP equivalent variable speed ball bearing direct drive motor allows the saw to run fast enough to use ultra-thin diamond blades
2) Speed varies from 400 to 3250RPM
Saw Table and Housing
1) The saw table is flat so it is easy to trim oversized slabs and removable so clean up is easy
2) Max. Sample loading length: 6"
3) The sturdy table measures 6"x 10", easy to operate
4) The saw housing is made of unbreakable cross-linked polyethylene-no rusting, no messy oil,
uses water only
5) Max. Cutting depth: 25.4mm
6) Max. Cutting width: 40mm( limited by the max. Opening of the sample holder)
Cutting Blade
1) Diamond 4"( Dia) x 0.014"( thick) x 0.5" (arbor), as well as a mini- vise which allows you to handle the sample smoothly
2) To cut soft material, such as stainless steel, Ni, Cu or plastic, please choose the 4" SiC blade
3) For longer cutting life, please use sintered diamond blade
Dimensions: 15" x 12" x 11"
Weight: 10kg
Warranty: One year
