| Prod Model: |
OMT 630 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Big |
| Flang Shape: |
Square and Rhombus Flange |
| Motor Power: |
Hydraulic Oil |
| Hydraulic Power Units: |
Screw Pump |
| Color: |
No Paint/ Black/ Iron Ash |
| Material: |
Cast Iron |
| Structural Style: |
Cycloid |
| Appliction: |
for Havy Machine |
| Hydraulic Motor Shafts: |
Straight, Splined and Tapered |
| Motor Operate: |
with Electrical Machine/Pump /Cyclinder/Valve/ |
Product Description
BMT series motor adapt the advanced Gerolor gear set design with disc distribution flow and high pressure. The unit can be supplied the individual variant in operating multifunction in accordance with requirement of applications.
Characteristic features:
* Advanced manufacturing devices for the Geroler gear set, which use low pressure of start-up, provide smooth and reliable operation and high efficiency .
* The output shaft adapts in tapered roller beadrings that permit high axial and radial forces. Can offer capacities of high pressure and high torque in the wide of applications.
* Advanced design in disc distribution flow, which can automatically compensate in operating with high volime efficiency and long life, provide smooth and reliable operation.
type | BMT | BMT | BMT | BMT | BMT | BMT | BMT | BMT | BMT |
| displacement | 160 | 200 | 230 | 250 | 315 | 400 | 500 | 630 | 800 |
| speed | 625 | 625 | 536 | 500 | 380 | 305 | 240 | 196 | 154 |
| torque | 470 | 590 | 670 | 730 | 950 | 1080 | 1220 | 1318 | 1464 |
| output | 27.7 | 34.9 | 34.7 | 34.5 | 34.9 | 31.2 | 28.8 | 25.3 | 22.2 |
| pressure | 20 | 20 | 20 | 20 | 20 | 18 | 16 | 14 | 12.5 |
| flow | 100 | 125 | 125 | 125 | 125 | 125 | 125 | 125 | 125 |
| weight | 19.5 | 20 | 20.4 | 20.5 | 21 | 22 | 23 | 24 | 25 |
Applications : Hydraulic motors are ideally suited for Applications demanding vary high Torque at low or variable speeds, along with economy, compact size, reliability, maintenance-free service etc. These motors also provide a cost effective alternative to many other variable speed drives in vogue.
Packaging details:
1. Industrial packing: plastic tube +carton+wooden pallets
2. Commercial packing: plastic bag +color box+wooden pallets
3. The transportation as per your request
Our company professional produce all kinds of hydraulic motors and related parts that can meet all your need. We have the experienced engineers to select the appropriate models for you.
Warranty:
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems caused by our
quality of production or raw material. Pls provide the defective appearance and related invoice number.
3. Sorry for you should responsible for the freight come-and-go,and the custom tax.
4. After expiration, our company can provides cost spare-parts maintenance for engines.
5. To save the cost,you can choose send the motor back without packing.
6. My dear friend, your emails can be get within one business day. If you do not receive our reply, please kindly re-sent
your email or give us a call any time.
Company Information
Established in 2004, Dongguan Blince Machinery & Electronics Co., Ltd.
Specializes in the business of hydraulic motor, cycloid motor, vane pump and hydraulic valve.Located in Changan, Dongguan, Guangdong, where we enjoy the
convenient access to major transportation networks. Our factory covers an area of
30,000 square meters and has about 361 staffs. Furthermore, our engineers have decades of experience in hydraulic area, all the products are manufactured with advanced equipment and strict QC procedures in order to ensure high quality. Copperate with us, you will have the stably, timely and credible supply.
Have any Questions, welcome to contact Sali, I'm gald to service you in Model selection giude!
Established in 2004, Dongguan Blince Machinery & Electronics Co., Ltd. Specializes in the business of hydraulic motor, cycloid m...MoreEstablished in 2004, Dongguan Blince Machinery & Electronics Co., Ltd. Specializes in the business of hydraulic motor, cycloid motor, vane pump and hydraulic valve. Located in Changan, Dongguan, Guangdong, we enjoy convenient access to major transportation networks. Our company covers an area of 30, 000 square meters and has around 361 people staff members. Furthermore, all our products are manufactured with advanced equipment and strict QC procedures in order to ensure high quality. With stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.
Blince main product is orbit motor like (OMM/OMP/OMR/OMH/OMT/OMS/OMV), Radial Piston Motor(NHM 1/2/3/6/8/11/16/31), hydraulic pump (PV2R series, V/VQ series, SQP series) valve and a set of hydraulic system.
Our product widely application for fishing machinery, agricultural machinery, engineering machinery, mining machinery, industrial machinery, aviation and transport machinery et
Blince hydraulic motor Can perfect replace:
Danfoss: OMM/OMP/OZ/OMR/OK/OMH/OMS/OMT/OMV orbital motor
Eaton: J (129-) series, H(101-) series, S(103-) series, T(158-)series, 2000(104-) series, 6000 series orbit motor
White: MP/RS/MR/RG/HB/CE/RE series hydraulic motor
Parker: TE and TG series hydraulic motor
