Hot Sell Manufacture Machine Parts Tapered Roller Bearing 30211

Name: Hot Sell Manufacture Machine Parts Tapered Roller Bearing 30211
Brand: tool-buy.com
SKU: 714338322
Availability: InStock
Rating: 4.4 (129 reviews)

Price:	US $ 0.01/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Guangzhou Wafangdian Bearing Co., Ltd.

Showroom Product Company Profile

Prod Model:	30211
Sample:	Available
Service:	OEM
Customer Brand:	Acceptable
Logo:	Customize
MOQ:	1000sets
Fob Port:	Qingdao,China
Stock:	Yes
Delivery Date:	7 Days
Customize Order:	Acceptable
Size:	Standard Size
Type:	Wheel Hub Bearing
Material:	Chrome Steel
Tolerance:	P0
Certification:	TUV
Clearance:	C0
ABS:	Without ABS
Brand:	Lyaz/OEM
Application:	All

Product Description

Quick Details

Structure:	Taper	Type:	Roller	Brand Name:	OEM or LYAZ
Bore Size:	15 - 160 mm	Outside Diameter:	60 - 250 mm	Model Number:	all types
Precision Rating:	P0 P6 P5 P4 P2	Seals Type:	Open	Number of Row:	Single Row
Place of Origin:	Hebei, China (Mainland)	Material:	Chrome Steel, GCR15, Carbon Steel, Stainless Steel	Certificate:	ISO 9001:2008 ISO/TS 16949
Feature:	Long Life, High Speed, Low Noise, Low Libration, High Pressure	Service:	OEM, Free Sample, Fast Delivery	Quality:	Top, Best, Good, Fine
HARDNESS:	60--65HRC	Stock:	Large	Delivery time:	5-30DAYS, Fast
Main market:	Europe, America, Asia, etc	Application:	Automotive, Machinery, Mining, etc

Packaging & Delivery

Packaging Details:	1)plastic tube+Kraft Paper +carton pallet 2)1piece//pp bag+color carton box+master carton +pallet 3)As customers' requirements
Delivery Detail:	5-30 days after placing the order or according to qty

Series models specification:

Bearing models	Dimensions			Limited speed rating		Load ratings		Appro weight(kg)
Bearing models	ID(mm)	OD(mm)	Thickness (mm)	Grease	Oil	Dynamic(N)	Static(N)	Appro weight(kg)
30303	17	47	15.25	9200	12000	27400	24500	0.129
30304	20	52	16.25	8300	11000	31500	33200	0.165
30305	25	62	18.25	6900	8700	49200	48100	0.265
30306	30	72	20.75	5900	7500	61300	62600	0.387
30307	35	80	22.75	5200	6600	78400	82000	0.518
30308	40	90	25.25	4600	5800	95200	107500	0.746
30309	45	100	27.25	4100	5200	114000	129700	0.988
30310	50	110	29.25	3800	4800	122300	154500	1.28
30311	55	120	31.5	3400	4300	158700	184700	1.63
30312	60	130	33.5	3200	4000	177600	207000	2.003
30313	65	140	36	2900	3700	203700	239400	2.43
30314	70	150	38	2700	3500	228100	269600	3.006
30315	75	160	40	2600	3200	264800	318700	3.57
30316	80	170	42.5	2400	3000	297000	352400	4.27
30317	85	180	44.5	2300	2900	319400	388100	4.958
30318	90	190	46.5	2100	2700	358300	440800	5.79
30319	95	200	49.5	2000	2600	368500	477700	6.782
30320	100	215	51.5	1700	2400	350000	343000	8.22
30321	105	225	53.5	1500	1900	432000	562000	9.38
30322	110	240	54.5	1400	1800	472000	612000	11
30324	120	260	59.5	1500	7000	435000	410000	14.2
30326	130	280	63.75	1400	1800	563000	684000	17.4
30328	140	300	67.75	1300	1700	626C00	761000	27.2
30330	150	320	72	970	1400	616000	750000	25.5

item	size(mm)			weight(kg)
item	d	D	B	weight(kg)
09067/09195	19.05	49.225	18.034	0.1804
09081/09195	20.625	49.225	19.845	0.1555
LM11749/LM11710	17.462	39.878	13.843	0.083
LM11949/LM11910	19.05	45.237	15.494	0.125
M12649/M12610	21.43	50.005	17.526	0.174
LM12749/LM1270	21.43	45.237	15.494	0.118
LM12749/LM1270	22	45.237	15.494	0.116
LM12749/LM1271	22	45.975	15.494	0.121
14125A/14276	31.75	69.012	19.845	0.354
14137A/14276	34.925	69.012	19.845	0.331
14138A/14276	34.925	69.012	19.845	0.329
25877/25821	34.925	73.025	23.812	0.473
25880/25821	36.487	73.025	23.812	0.458
2785/2720	33.338	73.025	23.812	0.544
2788/2720	38.1	76.2	23.813	0.499
2788/2729	38.1	76.2	23.813	0.503
2790/2720	33.338	76.2	23.812	0.549
2790/2729	33.338	76.2	23.812	0.555
28580/28521	50.8	92.075	24.608	0.707
28584/28521	52.388	92.075	24.608	0.682
28985/28920	60.325	101.6	25.4	0.81
29590/28522	66.675	107.95	25.4	0.874
29685/29620	73.025	112.712	25.4	0.893
LM29749/LM29710	38.1	65.088	18.034	0.239
HM518445/HM518410	88.9	152.4	39.688	2.886
575/572	76	139.992	36.512	2.398
593/592A	88.9	152.4	39.688	2.79
593/593A	95.25	152.4	39.688	2.53
598A/592A	92.075	152.4	39.688	2.65
580/572	82.55	139.992	36.512	2.178
LM603049/LM603011	45.242	77.788	19.842	0.368
LM603049/LM603012	46.242	77.788	21.43	0.386
L610549/L610510	63.5	94.458	19.05	0.46
LM67048/LM67010	31.75	59.131	15.875	0.189
14138A/14276	34.925	69.012	19.845	0.329
15101/15245	25.4	62	19.05	0.303
15123/15245	31.75	62	18.161	0.246
15126/15245	31.75	62	19.05	0.257
15113/15245	28.575	62	19.05	0.281
1755/1729	22.225	56.896	19.368	0.254
17887/17831	45.23	79.985	19.842	0.41
18590/18520	41.275	7.025	16.667	0.285
LM104949/LM104911	50.8	82.55	21.59	0.42
JLM104948/JLM104910	50	82	21.5	0.435
LM104949/LM104910	50.8	82	21.976	0.418
JLM104948/JLM104911	50	82.55	21.115	0.424
LM104949/LM104912	50.8	82.931	21.59	0.441
LM102949/LM102910	45.242	73.431	19.558	0.315
LM300849/LM300811	41	68	17.5	0.242
33275/33462	69.85	117.475	30.162	1.272
33281/33462	71.438	117.475	30.162	1.231
33889/33821	50.8	95.25	27.783	0.868
33287/33462	73.025	117.475	30.162	1.188
368A/362A	50.8	88.9	20.638	0.504
368/362	50.8	90	20	0.562
3780/3720	50.8	93.254	30.162	0.856
3720/3720	44.45	93.264	30.162	0.97
387A/382A	57.15	96.838	21	0.599
39585/39520	63.5	112.712	30.162	1.258
2580/2523	31.75	69.85	23.812	0.454
28985/28921	60.325	100	25.4	0.77
47686/47620	82.55	133.35	33.338	1.757
47687/47620	82.55	133.35	33.338	1.737
387A/362S	57.15	96.838	25.4	0.669
387A/382	57.15	98.425	21	0.649
3982/3920	63.5	112.712	30.162	1.243
3984/3920	66.675	112.712	30.162	1.166
462/453X	57.15	104.775	30.162	1.07
L44643/L44610	25.4	50.292	14.224	0.129
L4469/L44610	26.988	50.292	14.224	0.12
L45449/L45410	29	50.292	14.224	0.115
LM48548/LM48510	34.925	65.088	18.034	0.259
LM501349/LM501210	41.275	73.431	19.558	0.334
LM501349/LM501314	41.275	73.431	21.43	0.355
HM212047/HM212011	63.5	122.238	38.1	1.938
HM212049/HM212011	66.675	122.238	38.1	1.848
hm218248/hm218210	90	147	40	2.566
m84548/m84510	25.4	57.15	19.431	0.245
hm801346/hm803110	41.275	88.9	30.162	0.901
hm801346/hm803110	44.45	88.9	30.162	0.85
24780/2470	41.275	76.2	22.225	0.429
25570/25520	36.513	82.931	23.813	0.651
25572/25520	38.1	82.931	23.813	0.642
25580/25520	44.45	82.931	23.812	0.561
25581/25520	45.45	82.931	23.812	0.563
25590/25520	45.618	82.931	23.812	0.546
25590/25523	45.618	82.931	26.988	0.591
25877/25821	34.925	73.025	23.812	0.473
25577/25523	42.875	82.931	26.988	0.629
33287/33462	73.025	117.475	30.162	1.188
L68149/L68110	35	59.975	15.875	0.181
L68149/L68111	35	59.975	15.875	0.181
JL69349/JL69310	38	63	17	0.203
HM802047/HM802011	41.275	82.55	26.543	0.636
M86649/M86610	30.162	64.292	21.433	0.339
M88048/M88010	33.338	68.262	22.225	0.382
HM88649/HM88610	34.926	72.233	25.4	0.495
JLM506849/JLM506810	55	90	23	0.564

Packaging & Delivery

Packaging Details:	1. craft paper rolled/plastic bucket +carton +pallet 2.individually packing +carton +pallet 3.As customer's request tapered roller bearing size chart 30202 30203 30204 30205 30206
Delivery Detail:	Shipped in 15 days after payment

Product Description

tapered roller bearing size chart 30202 30203 30204 30205 30206 specification

Tapered roller bearing type belongs to the separation bearing, have tapered roller bearing inner and outer race.According to these bearings on the column number of the roller is divided into single row, double row and four row circular cone roller bearings these different structure. Single row circular cone roller bearings can bear radial load and the single direction axial load. When bearing radial load, axial force component, would create a so when need another affordable bearing axial force in the opposite direction to balance

Application

tapered roller bearing size chart 30202 30203 30204 30205 30206 uses:

Tapered roller bearing is widely used in automotive, rolling mill, mining, metallurgy, plastics machinery and other industries.

Specification

tapered roller bearing size chart 30202 30203 30204 30205 30206 specification:

bearing	sizemm				/kN		weight/kg	old meodel
bearing	d	D	T	B	Cr	Cor	W≈	old meodel
30202	15	35	11.75	11	0.0	0.0	0.050	7202E
30203	17	40	13.25	12	20.8	21.8	0.079	7203E
30204	20	47	15.25	14	28.2	30.5	0.126	7204E
30205	25	52	16.25	15	32.2	37.0	0.154	7205E
30206	30	62	17.25	16	43.2	50.5	0.231	7206E

tapered roller bearing size chart 30202 30203 30204 30205 30206 details picture:

Wafang Dian Bearing Advantage

1. Material Advantage
All the material for Wafang Dian bearing are from the best suppliers in China.

2. Processing Advantage
we can guarantee the time spent and quality of every processing. We can do three times tempering to stabilize the dimensions of the bearings, which is quite different from other bearings manufacturers.

3. Quality control advantage
All the bearing parts are 100% strictly inspected before and during production including Metallurgical testing, crack detection, roundness, hardness, roughness and g++eometric dimensions.

4. All of bearings meet the ISO international standard.

5. Appearance Technology Advantage
we can provide light chamfer, black chamfer, black chamfer of the rollers. The bearings are produced all according to customer's requirements.

6. Service Advantage
Your satisfaction is our biggest goal. From quotation to the final packing and transport, we provide the quickest and most satisfactory services to every customer.

We participate Canton Fair,Shanghai Auto Mechanika Fair,Professional Auto Parts Fair annually.

Welcome Inquiry and order !
Thank you!

Guangzhou Wafangdian Bearing Co., Ltd. is a professional bearing company, belongs to Liaoning Wafang Dian Aoli Yuan Bearing Manufacturing Co. Ltd, , locates in Wafangdian north Gongji street, covers an area of more than 50000 square meters, over 300 staffs work in the factory. The annual production is more than 10 million sets of various bearings.

We have more than 30 years bearing manufacturing experience, execute strict and responsible quality control. Our products are: Deep groove ball bearing, tapered roller bearing, cylindrical roller bearing, spherical roller bearing, thrust ball bearing, needle bearing, self-aligning ball bearing, angular contact ball bearing, pillow block bearing, wheel hub bearing, clutch bearing, composite bearing and all kinds of non-standard bearings. Our bearings are low noise, long working life, high precision, high speed, heavy duty, good temperature resistance, widely used in automobiles, machine tools, mining, oil field, paper making, cement plant, power plant, steel mill, construction machinery and many other industries.

We are strong in research and development. We can design and produce bearings with drawings or samples to meet customers' specific needs. OEM services are also provided with customers' authorization. Small orders are accepted, free samples are available. We guarantee high quality, competitive prices, on-time delivery, fast response. Welcome all distinguished guests at home and abroad to contact us for business, looking forward to working with you hand in hand, create more brilliant future together!
