Laser Cutters for Home Use
| Price: |
US $ 3500-4900/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union |
Product Description
laser cutters for home use is a technology that uses a laser beam to cut materials, and is typically used for industrial manufacturing applications, but is also starting to be used by schools, small businesses, and hobbyists. Laser cutting works by directing the output of a high-power laser most commonly through optics.
laser cutters for home use Specification:- Packing: plywood case
- Voltage : 220V/ 60Hz
- Net Weight: 465KG
- Laser tube power: 50W
- Working size: 1300x900mm
- Resolution ratio: ≤4500dpi
- Laser type: hermetic CO2 glass tube
- Worktable: DC -up&down table
- Compatible software: CorelDraw, AutoCAD(not included in this item)
- Machine Dimension:3210×1950×1350 mm
- laser head to the lifting platform distance: 22.5cm
laser cutters for home use Applicable Material:| Material | Engrave | Cut |
| Wood | Yes | Yes |
| Jade | Yes | |
| Acrylic | Yes | Yes |
| Glass | Yes | |
| Ceramic | Yes | |
| Delrin | Yes | Yes |
| Cloth | Yes | Yes |
| Leather | Yes | Yes |
| Marble | Yes | |
| Matte Board | Yes | Yes |
| Melamine | Yes | Yes |
| Paper | Yes | Yes |
| Mylar | Yes | Yes |
| Press Board | Yes | Yes |
| Rubber | Yes | Yes |
| Wood Veneer | Yes | Yes |
| Fiberglass | Yes | Yes |
| Tile | Yes | |
| Plastic | Yes | Yes |
| Cork | Yes | Yes |
| Corian | Yes | Yes |
| Ceramics | Yes | |
laser cutters for home use Package Included- 1x Main Body
- 1x Air Pump
- 1x Exhaust Fan
- 1x Smoke Pipe
- 1x Laser Tube
- 1x USB Cable
- 1x Power Line
- 1xSet Wrench
- 1x Water Pump
- 1x Accessory Bag
- 1x English Manual
- 1x CD
laser cutters for home use technical parameters| laser cutters for home use | |
| Product Type | laser cutters for home use |
| Model | YN-6090 |
| Effective area | 600*900mm |
| Laser power | 130w |
| Laser type | Beijing EFR,RECI |
| Cooling mode | Water cooling |
| Engraving scanning speed | 0-60000mm/min |
| Cutting speed | 0-30000mm/min |
| Laser energy control | 1-100% software setting |
| Mini-shaping character | Chinese character2.0*2.0mm,English1.0*1.0mm |
| Max-scanning precision | 4500DPI |
| Positioning precision | 0.01mm |
| Supported graphic format | DSP PLT BMP DXF AI |
| Operating system | Windows98/ME/2000/XP/VISTA/2007 |
| power | AC110V-220V+10%,50-60HZ |
| Driving system | Stepper motor |
| Material thickness as a reference | Solid wood 5mm,acrylic 25mm,PVC 25mm,leather 4mm |
Note:- This item is very heavy and cannot ship out through Fedex or UPS. This item requires special truck delivery and we will need your correct phone number in order to schedule delivery . The included service is delivery to your address. It does not include lift gate service, installation or delivery inside the house. If you need the lift gate service, please contact us before making the purchase!
- Please provide us with the valid commercial address. If your delivery address is private residence address, contact us before you place an order.
Warranty and other details with laser cutters for home use - 1.5 years free warranty
- Provides excellent after-sales service - Safety certificate for machine
- FDA compliant, CE certification, ISO9001 quality certification - The manual up/down table
- It is suitable for different sizes of carving items - A red dot pointer
- Provides visibility and shows the engraving location. - Control panel
- Easy to use, the speed, power and other settings can adjust. - With 100W CO2 laser tube
- The engraving will be smooth and precise. - The Raster/Vector color mapping
- Allows you to change the engraving speed and power through color coding. - The reinforced and thickened machine body
- Makes transportation absolutely to be safer and longer life time. - USB connectivity and U-Flash disk supported
- USB connectivity for easy observation from your computer
- U-Flash disk for the machine will read files from memory stick,you can work even without a PC. - Water cooling and protection system
- Can reduce the laser tube's temperature and help it work for a longer time - Air assist function and exhaust fan system
- Helps the cutting surface always to clean the debris, gases and heat and makes the engraving and cutting projects a breeze - Mainboard and chip & bearing & high accuracy stepping belt
- Mainboard and chip adopt Japan imported which can control the engraving more precise
- Bearing & high accuracy stepping belt adopt Germany imported, which not only make the engraving more precise, also make the machine life time twice to three times than ordinary CO2 laser engraver - Supports multiple graphic formats
- PLT / DXF / BMP / JPG / GIF / PGN / TIF and others. Equipped with a DSP control system for CorelDraw/AutoCAD and other advance software, this machine is compatible with Win 7, Win 8, Vista, XP and Win 2000.
