Prod Model: |
mdl-c160 |
Application: |
Construction Engineering Supporting, Slope Support |
Dimensions (L×w×h): |
5400*2200*2200mm |
Product Description
Quick Detail:
1.The top driven anchor drill rig is stable,high effiency and can be used for complex stratums,such as sand gravel layer, gravel layer, sand stone soil, sand.
2. The top of the power head can vibrate with big power without DTH hammer or air compressor.
3. The drilling tools from the outer to the inner and all involved in the transmission of the impact power, it is not easy to happen the hole accidents such as drill sticking.
4. MDL-C160 is applicable to a wide-range of strata with big torque, high rotary speed, and big power.When meeting those fragile holes , the top drive drill equipment has a very high penetration rate and drilling efficiency.
5. Especially when the moisture content of local layer is too high to use DTH hammer when work, this top head drive drill rig is the only choice.
Description:
1. MDL-C160 is top driven anchor drilling rig imported from Taiwan,so it can drill in a compact way.
2. MDL-C160is applicable to a wide-range of strata with big torque, high rotary speed, and big power.
3. When meeting those fragile holes such as sand gravel layer, gravel layer, sand stone soil, sand hole, the top drive drill equipment has a very high penetration rate and drilling efficiency. Especially when the moisture content of local layer is too high to use DTH hammer when work, this top head drive drill rig is the only choice.
4. This top head drive drill rig adopts variable hydraulic system and can vibrate with big power without DTH hammer or air compressor.The drilling tools from the outer to the inner and all involved in the transmission of the impact power, it is not easy to happen the hole accidents such as drill sticking.
5. This top drive drill equipment is applicable to anchor hole, such as urban foundation pit supporting . And is mainly applied to construction engineering supporting, slope supporting,all kinds of guide hole, tunnel and pipe shed engineering, etc.
Applications:
1. Anchor hole, such as urban foundation pit supporting .
2. It is mainly applied to construction engineering supporting, slope supporting,all kinds of guide hole, tunnel and pipe shed engineering, etc.
Specifications:
Hole depth | 130-170m |
Rod dia | 150-250mm |
Hole angle | 0-90° |
Output rotary speed of power head | 8, 15, 25,30,50, 65, 80r/min |
Stroke of power head | 3000mm |
Output torque of power head | 10000N.m |
Impact power | 400-600N.m |
Impact frequency | 1500-2600min-l |
Lifting force | 78KN |
Feeding force | 40KN |
Stroke of slide frame | 1500mm |
Power | Electric motor: | 55+18.5+3KW |
Weight | 7000KG |
Dimensions (L×W×H) | 5400×2200×2200mm |
Jiangsu Wuxi Mineral Exploration Machinery General Factory Co., Ltd. (brief name: Jiangsu XiTan ) was was founded in 1956 with a registered capital of 20 million and is a large-scale key enterprise in the industry of geological exploration field.
Our factory covers more than 60, 000 square meters. Equipped with more than 60 years professional manufacturing experience and professional production team as well as more than 200 excellent skillful workers, more than 20 experienced engineers and more than four hundred sophisticated equipments, the high quality drilling equipments will be manufactured.
Our company has advanced and scientific production technology and capacity as well as rapid innovation ability, so that our products account for a large market share in the domestic market. At the same time, our drilling rigs have been exported to Vietnam, Brunei, Iran, Britain, Nigeria and other countries and regions.
We have received the ISO9001-2000 quality system certification. We also obtain the science and technology progress award and second prize issued by the China National Light Industry Association.
Our company is located in Wuxi City. It is 2 km away from the railway station, convenient in traffic and beautiful in environment.
Our company supplies different kinds of products. High quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
