01) Dimensions sliding table:3200×370mm |
02) Gross cut capacity:3200mm |
03) Width of cut between saw blade and rip fence:1250mm |
04) Standard accessory Saw blade (Capacity ):400mm (300-400mm) |
05) Height of cut with saw blade 400mm: 130mm |
06) Height of cut with saw blade 400mm at 45 degree: 90mm |
07) Speed of main saw blade:4000/6000rpm |
08) Spindle diameter:30mm |
09) Tilling saw blade:0-45° |
10) Main motor:5.5kw |
11) Scoring saw blade:120mm |
12) Speed of scoring saw blade:8000r/min |
13) Spindle of scoring saw:20mm |
14) Motor:0.75kw |
15) N/G weight:640/730kgs, 130/190KGS |
16) Packing size : 2270x1220x1150mm, 3350x485x340mm |
17) Overall dimensions:3250x3150x900mm |
01) Dimensions sliding table:3200×370mm02) Gross cut capacity:3200mm
03) Width of cut between saw blade and rip fence:1250mm
04) Standard accessory Saw blade (Capacity ):400mm (300-400mm)
05) Height of cut with saw blade 400mm: 130mm
06) Height of cut with saw blade 400mm at 45 degree: 90mm
07) Speed of main saw blade:4000/6000rpm
08) Spindle diameter:30mm
09) Tilling saw blade:0-45°
10) Main motor:5.5kw
11) Scoring saw blade:120mm
12) Speed of scoring saw blade:8000r/min
13) Spindle of scoring saw:20mm
14) Motor:0.75kw
15) N/G weight:640/730kgs, 130/190KGS
16) Packing size : 2270x1220x1150mm, 3350x485x340mm
17) Overall dimensions:3250x3150x900mm
Main Features and Standard fitting :
1) 50mm diameter rip fence channel
2) Type-A protection hood
3) Manual saw blade tilting 45 degree
4) Max saw blade capacity 400mm
* Y style sliding table fitted as standard
