Panel Saw with 3200mm Sliding Table (SMJ6132TYA)

Name: Panel Saw with 3200mm Sliding Table (SMJ6132TYA)
Brand: tool-buy.com
SKU: 662196481
Availability: InStock
Rating: 4.9 (90 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	5/Piece
Pay Type:	L/C,T/T

Contact Supplier

Burt Group Co., Ltd.

Showroom Product Company Profile

Prod Model:	SMJ6132TYA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Gross Cut Capacity:	3200mm
Width Of Cut:	1250mm
Height Of Cut:	90mm
Type:	Table Panel Saw
Layout:	Horizontal
Controlling Mode:	Artificial
Automatic Grade:	Semiautomatic
Precision:	High Precision
Certification:	CE

Product Description

Main Features and Standard fitting:

01) Dimensions sliding table: 3200x370mm

02) Gross cut capacity: 3200mm

03) Width of cut between saw blade and rip fence: 1250mm

04) Saw blade φ : 300mm-400mm

05) Height of cut φ 300mm: 90mm

06) Diameter of guide shaft spindle: 50mm

07) Height of cut with saw blade φ 300mm at 45° : 60mm

08) Speed of main saw blade: 4000/6000rpm

09) Spindle diameter: 30mm

10) Tilling saw blade: 0-45°

11) Main motor: 5.5kw

12) Scoring saw blade: 120mm

13) Speed of scoring saw blade: 8000r/min

14) Spindle of scoring saw: 20mm

15) Motor: 0.75kw

16) Net weight: 770kg

17) Gross weight (wooden packing case): 920kg

18) Overall dimensions: 3250x3150x900mm

01) Dimensions sliding table: 3200x370mm
02) Gross cut capacity: 3200mm
03) Width of cut between saw blade and rip fence: 1250mm
04) Saw blade φ : 300mm-400mm
05) Height of cut φ 300mm: 90mm
06) Diameter of guide shaft spindle: 50mm
07) Height of cut with saw blade φ 300mm at 45° : 60mm
08) Speed of main saw blade: 4000/6000rpm
09) Spindle diameter: 30mm
10) Tilling saw blade: 0-45°
11) Main motor: 5.5kw
12) Scoring saw blade: 120mm
13) Speed of scoring saw blade: 8000r/min
14) Spindle of scoring saw: 20mm
15) Motor: 0.75kw
16) Net weight: 770kg
17) Gross weight (wooden packing case): 920kg
18) Overall dimensions: 3250x3150x900mm

Main Features and Standard fitting:
01) 50mm diameter Guide shaft spindle
02) Full size extentioin tables in right side and rear side
03) Lubricatioin pump
04) Support feeding frame
05) 2ND generation front control panel hood
06) Type-R protection hood
07) Advanced LED readout
08) Main motor 5.5KW
09) Scoring motor 0.75KW
10) Hold down clamp
11) Manual tilting 45 degree
