Razor Wire:
Barbed Wire
Material:
Galvanized Steel Wire
Application:
Fence Mesh
Finish:
Hot Dipped Galvanized
Razor Barbed Type:
Single Razor
Wire Gauge:
12x12 BWG
Barbed Distance:
3"
Barb Length:
22mm
Coil Outside Diameter:
450mm
Twist Method:
Galvanized, PVC Coated
Color:
Galvanized, PVC Coated
Product Description
Razor bared wire,plastic barbed wire,Anping barbed wire,Hot dip galvanized razor wire,razor edge barbed wire,razor wire cbt-60,spiral razor barbed wire,plastic razor wire,razor barbed wire netting,razor barbed iron wire mesh,green razor barbed wire,concertina razor barbed wire 1.Materials:galvanized iron wire,PVC coated wire ,stainless steel wire and stainless steel sheet 2.Blade Type:BTO-12 BTO-18 BTO-22 CBT-60 CBT-65 3.Wire Dia.:2.0-2.5mm 4.Bard Length:10-65mm 5.Barb Spacing:26-100mm 6.Classification:straight line razor wire,concertina wire,crossed razor barbed wire,razor wire mesh 7.Process and Features:Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.The products offer beautiful appearance,economic cost,good frightening result and easy installation.Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive perimeter intruders . 8.Applications:widely used in military field,prisons,detention houses,government buildings and other national security facilities.Also fencing of residences,villa wall and windows,express way,railway,national border lines,ets.
9.Specifications
Razor Blade Type and Specification
Reference Number
Thickness
Wire Diameter
Barb Length
Barb Width
Barb Spacing
BTO-10
0.5 ± 0.05
2.5 ± 0.1
10 ± 1
13 ± 1
26 ± 1
BTO-12
0.5 ± 0.05
2.5 ± 0.1
12 ± 1
15 ± 1
26 ± 1
BTO-18
0.5 ± 0.05
2.5 ± 0.1
18 ± 1
15 ± 1
33 ± 1
BTO-22
0.5 ± 0.05
2.5 ± 0.1
22 ± 1
15 ± 1
34 ± 1
BTO-28
0.5 ± 0.05
2.5 ± 0.1
28 ± 1
15 ± 1
45 ± 1
BTO-30
0.5 ± 0.05
2.5 ± 0.1
30 ± 1
18 ± 1
45 ± 1
Outer diameter
No. of loops
Standard length per coil
Type
Notes
450mm
33
7m-8m
CBT-65
Single coil
500mm
41
10m
CBT-65
Single coil
700mm
41
10m
CBT-65
Single coil
960mm
54
11m-15m
CBT-65
Single coil
500mm
102
15m-18m
BTO-12,18,22,28,30
Cross type
600mm
86
13m-16m
BTO-12,18,22,28,30
Cross type
700mm
72
12m-15m
BTO-12,18,22,28,30
Cross type
800mm
64
13m-15m
BTO-12,18,22,28,30
Cross type
960mm
52
12m-15m
BTO-12,18,22,28,30
Cross type
Shenzhou AnDeSen Wire Fencing Co., Ltd is a big wire mesh manufacturer located in Shenzhou of Hebei Province. AnDeSen is specialized in wire drawing, galvanizing and wire mesh weaving. With over 200 sets of production machines, first-class technology, excellent management system and R & D capability, we have won trust and praises from many customers.
