Razor Barbed Wire (Galvanized and SUS)
| Price: |
US $ 600/Ton |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
5/Ton |
| Pay Type: |
L/C,T/T,D/P,Western Union |
| Prod Model: |
BTO-18 BTO-22 CBT-65 CBT-60 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Razor Wire: |
Barbed Wire |
| Material: |
Galvanized Steel Wire |
| Application: |
Fence Mesh |
| Finish: |
Hot Dipped Galvanized |
| Razor Barbed Type: |
Single Razor |
| Wire Gauge: |
12x12 BWG |
| Barbed Distance: |
3" |
| Barb Length: |
22mm |
| Coil Outside Diameter: |
450mm |
| Twist Method: |
Galvanized, PVC Coated |
| Color: |
Galvanized, PVC Coated |
Product Description
Razor bared wire,plastic barbed wire,Anping barbed wire,Hot dip galvanized razor wire,razor edge barbed wire,razor wire cbt-60,spiral razor barbed wire,plastic razor wire,razor barbed wire netting,razor barbed iron wire mesh,green razor barbed wire,concertina razor barbed wire1.Materials:galvanized iron wire,PVC coated wire ,stainless steel wire and stainless steel sheet2.Blade Type:BTO-12 BTO-18 BTO-22 CBT-60 CBT-653.Wire Dia.:2.0-2.5mm4.Bard Length:10-65mm5.Barb Spacing:26-100mm6.Classification:straight line razor wire,concertina wire,crossed razor barbed wire,razor wire mesh7.Process and Features:Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.The products offer beautiful appearance,economic cost,good frightening result and easy installation.Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive perimeter intruders .8.Applications:widely used in military field,prisons,detention houses,government buildings and other national security facilities.Also fencing of residences,villa wall and windows,express way,railway,national border lines,ets.
9.Specifications| Razor Blade Type and Specification |
| Reference Number | Thickness | Wire Diameter | Barb Length | Barb Width | Barb Spacing |
| BTO-10 | 0.5 ± 0.05 | 2.5 ± 0.1 | 10 ± 1 | 13 ± 1 | 26 ± 1 |
| BTO-12 | 0.5 ± 0.05 | 2.5 ± 0.1 | 12 ± 1 | 15 ± 1 | 26 ± 1 |
| BTO-18 | 0.5 ± 0.05 | 2.5 ± 0.1 | 18 ± 1 | 15 ± 1 | 33 ± 1 |
| BTO-22 | 0.5 ± 0.05 | 2.5 ± 0.1 | 22 ± 1 | 15 ± 1 | 34 ± 1 |
| BTO-28 | 0.5 ± 0.05 | 2.5 ± 0.1 | 28 ± 1 | 15 ± 1 | 45 ± 1 |
| BTO-30 | 0.5 ± 0.05 | 2.5 ± 0.1 | 30 ± 1 | 18 ± 1 | 45 ± 1 |
| Outer diameter | No. of loops | Standard length per coil | Type | Notes |
| 450mm | 33 | 7m-8m | CBT-65 | Single coil |
| 500mm | 41 | 10m | CBT-65 | Single coil |
| 700mm | 41 | 10m | CBT-65 | Single coil |
| 960mm | 54 | 11m-15m | CBT-65 | Single coil |
| 500mm | 102 | 15m-18m | BTO-12,18,22,28,30 | Cross type |
| 600mm | 86 | 13m-16m | BTO-12,18,22,28,30 | Cross type |
| 700mm | 72 | 12m-15m | BTO-12,18,22,28,30 | Cross type |
| 800mm | 64 | 13m-15m | BTO-12,18,22,28,30 | Cross type |
| 960mm | 52 | 12m-15m | BTO-12,18,22,28,30 | Cross type |
