| Prod Model: |
MJ12-2800 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Cross Cut Length: |
2800mm |
| Type: |
Table Panel Saw |
| Layout: |
Vertical |
| Controlling Mode: |
Artificial |
| Automatic Grade: |
Manual |
| Precision: |
Precision |
| Certification: |
CE |
Product Description
01) Motor Power: 3000W(three Phases)/ 2200W(single phase)
02) Major Table Size: 385X800mm03) Extension Table (Cast Iron): 440x800mm
04) Extension Table (Steel plate): 440x800mm
05) Rear Extension Table: 310X500mm
06) Sliding panel Size: 2800X270mm07) Cross Cut Table Size: 680× 580mm
08) Cross Cut Fence: 1200-2200mm
09) Main Blade Size: 315X30X3mm
10) Main Blade Speed: 4000rpm
11) Scoring Blade Size: 90X20X3mm
12) Scoring Blade Speed: 5800rpmm
13) Max Cut Depth: 100mm at 90 degree(315)
80mm at 45 degree(315)14) Max Distance-blade to rip fence: 1220mm
15) Max cross cut Length: 2800mm
16) Max cross Cut Width: 1350mm17) Packing Size: 16000x775x1040 mm
2860x250x320 mm
18) Weight(N, W/G, W): 240/300; 58/70kgs
19) Noise Level(Unload): 85dB(A)
20) Units/20'GP: 14PCS
| 01) Motor Power: 3000W(three Phases)/ 2200W(single phase) |
| 02) Major Table Size: 385X800mm |
| 03) Extension Table (Cast Iron): 440x800mm |
| 04) Extension Table (Steel plate): 440x800mm |
| 05) Rear Extension Table: 310X500mm |
| 06) Sliding panel Size: 2800X270mm |
| 07) Cross Cut Table Size: 680× 580mm |
| 08) Cross Cut Fence: 1200-2200mm |
| 09) Main Blade Size: 315X30X3mm |
| 10) Main Blade Speed: 4000rpm |
| 11) Scoring Blade Size: 90X20X3mm |
| 12) Scoring Blade Speed: 5800rpmm |
| 13) Max Cut Depth: 100mm at 90 degree(315) |
| 80mm at 45 degree(315) |
| 14) Max Distance-blade to rip fence: 1220mm |
| 15) Max cross cut Length: 2800mm |
| 16) Max cross Cut Width: 1350mm |
| 17) Packing Size: 16000x775x1040 mm |
| 2860x250x320 mm |
| 18) Weight(N, W/G, W): 240/300; 58/70kgs |
| 19) Noise Level(Unload): 85dB(A) |
| 20) Units/20'GP: 14PCS |
