| Prod Model: |
CK6432A |
| CNC System: |
GSK,Siemens |
| Spindle Bore: |
60mm |
| Max.Length Of Work Piece: |
700mm |
| Range Of Spindle Speed: |
100-2500rpm |
| Taper Of Spindle Bore: |
Mt6 |
| Max. Swim Over Bed: |
360mm |
| Stations Of Tool Carrier: |
4 |
| Motor Power: |
4kw |
| Packing Size (mm): |
1850 *1100 *1550mm |
| Net Weight: |
1450kg |
| Type: |
Horizontal Lathe |
| Processing Accessory: |
Chuck CNC Lathe |
| Tool Holder: |
Single-tool Holder CNC Lathe |
| Power Source: |
Electric |
| Controlling Mode: |
CNC |
| Automatic Grade: |
Semiautomatic |
| Setting Mode: |
Floor-type |
| Precision: |
High Precision |
Product Description
Big Power Small Metal CNC Lathe CK6432A(CK6432A)
Standard configuration:
1. System:GSK928TD-L,
2. 3 jaw manual chuck
3. 4 station tool
4. Manual tailstock
5. Lighting system
6. Cooling system
7. Automatic lubrication system
Optional accessories:
1) pneumatic chuck
2) hydraulic chuck
3) pneumatic tailstock
4) hydraulic tailstock
5) enlarged bord , two gears, variable frequency speed regulation
Specifications
ITEMS |
Specifications |
Max. swim over bed |
Φ360mm |
Max. swim over carriage |
Φ150mm |
Max. length of work piece |
450mm/700mm |
Range of spindle speed |
150-2500rpm |
Spindle bore |
Φ60mm |
Taper of spindle bore |
MT6 |
Stations of tool carrier |
4/6/8 or gang type tool carrier |
Max size of tool post |
20mm×20mm |
Min. setting unit of motor |
(Z) long 0.001mm,
(X) cross 0.001mm |
Moving speed of post |
(Z) long 8 m/min,
(X) cross 4 m/min |
Taper of tailstock quill |
MT4 |
Max. range of tailstock quill |
100mm |
Motor power |
4KW |
Packing size(length ×width ×height) |
1600/1850 mm×1100mm×1550mm |
Net weight |
1300/1450kg |
Main features:
1. Spindle brake way by electric brake.
2. May fix with hydraulic chuck system.
3. Integrated automatic lubrication system.
4. High precision CNC lathe with good performance-price radio.
5. Electronic hand wheel equipped easy operation.
