Laser Welded Diamond Saw Blade for Marble and Granite

Name: Laser Welded Diamond Saw Blade for Marble and Granite
Brand: tool-buy.com
SKU: 709461365
Availability: InStock
Rating: 4.5 (30 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CIF,DAP
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Quanzhou Keen Diamond Tool Co., Ltd.

Showroom Product Company Profile

Prod Model:	LQ600C
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item:	Diamond Saw Blade
Diameter:	From 300mm to 4200mm
Technology:	Laser Welded
Material:	Silent Core with Sintered Diamond Segment
Finishing:	Ti-Coated
Graininess:	300#
Shape:	Round
Usage:	Stone Cutting
Kind:	Wall Saw
Saw Blade External Diameter:	600mm

Product Description

Description
Laser welded diamond saw blade are widely used to cut openings in reinforced concrete or birck walls for the replacement of doors, windows, duets and for removing walls and floors for expansion or demolition, which is with fast cutting less fatigue, smooth operation and long life.

Wall saw blade for granite and marble
1. Diameter 300mm-4200mm
2. Laser welded
3.Sharpness, long lifespan
4. SGS, CE, A&V audited

Brief introduction of KEEN TOOL

KEENTOOL produces and export kinds of diamond saw blades for wet cutting stone like granite, marble etc, as well as construction materials like concrete, reinforced concrete, and asphalt.

Our advantages

The advantages of our saw blades are high strength of welding between diamond segment and steel blank, high cutting precision, fast cutting speed.

Quality control

All the material of saw blade we using now is good quality diamond and metallic bond, made by advanced technology and 10 years experience to ensure the perfect cutting and the best results.

Technical Data

Diamond Blades for Granite/Marble
Diameter		Length (mm)	Width (mm)	Height (mm)	Segment No.	Arbor size (mm)
Inch	Metric(mm)	Length (mm)	Width (mm)	Height (mm)	Segment No.	Arbor size (mm)
12"	300	40	3.0	10/12/15/20	21	50/60
14"	350	40	3.2	10/12/15/20	24
16"	400	40	3.4	10/12/15/20	28
18"	450	40	3.6	10/12/15/20	32
20"	500	40	4.0	10/12/15/20	36
24"	600	40	4.5	10/12/15/20	42
28"	700	40	5.0	10/12/15/20	50
32"	800	40	6.0	10/12/15/20	57
36"	900	24	6.5/7.5	13/15	64	100
40"	1000	24	6.5/7.5	13/15	70
48"	1200	24	7.0/8.0	13/15	80
64"	1600	24	8.2/9.2	13/15	108
72"	1800	24	9.0/10.0	13/15	120
80"	2000	24	9.5/10.5	13/15	128
110"	2500	24	11/12	15/20	140
120"	3000	24	11/12	15/20	160
135"	3500	24	12.5/13.5	15/20	180	150/200
155"	4000	24	13.5/14.5	15/20	200
165"	4200	24	13.5/14.5	15/20	210

Packaging & Shipping:
Packaging: Carton with water proof plastic.
Delivery time: In 15 days after receipt of payment

Always at your service!

Quanzhou Keen Diamond Tool Co., Ltd is one of the leading manufacturer of series machinery and diamond tools for natural stone quarry, processing and civil construction work, which has very good presentation in Europe, North&South America, Southern Africa, Middle East and Asian.

We are committed to professional total solution and package supply for natural stone quarry and controlled demolition of civil construction:

1. For stone Quarry:

Package supply of quarry machinery and consumables for quarries of granite, marble, sandstone, limestone, travertine and slate, such as Wire saw machine, DTH Drill, block trimming wire saw, diamond wire, generators and air compressors etc.

Consultant service for project evaluation, quarry development and mining construction

Consultant and marketing service for block distribution

2. For stone Factory:

Total solution and package supply of machinery and diamond tools for stone cutting, profiling, drilling and polishing, such as block cutting machine, bridge circular saw machine, bridge eage cutting machine, static stationary wire saw machine; Diamodn wire, diamond blade, diamond segments, diamond core drill, diamond fickert, diamond cup wheels and diamond polishing tools etc.

3. For civil construction:

Total solution and consult service for wire cutting of civil construction like old buildings, bridge, dams, highway, rail way, steel structure and underwater cutting of kinds of pipes.

Package supply of machinery, diamond wire and other consumables for wire cutting of civil construction

Diamond blade for cutting concrete, reinforced concrete and asphalt

Diamond Core Drills for concrete reinforced concrete, wall and asphalt

Diamond polisher for polishing of concrete floor, wall and blocks

The core values of our company is to create value for customers, provide opportunities for staff and make benefits for the society. Our principle for business is customer-oriented and quality first. Keen looks forward to cooperating with you.
