Prod Model: |
MDS250S |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Cutting Range At 90degree: |
Round 70mm |
Cutting Range At 45degree: |
Round 65mm |
Diameter Of Sawing Blade: |
250mm |
Speed Of Sawing Blade: |
40/80rate/Min |
Product Description
MDS250S TECHNICAL SPECIFICATIONS:
01) Cutting Range At 90degree: round 70mm , |
square 70x70mm, |
rectangle 95x55mm |
02) Cutting Range At 45degree: round 65mm, |
square 60x60mm, |
rectangle 65x55mm |
03) Diameter of sawing blade: 250mm |
04) Speed of sawing blade( rate/min) : 40/80 |
05) Motor power: 0.95/1.1KW (Two speed motor) |
06) N.W.: 85Kgs |
07) Packing size: (1)1030X570X760MM, |
(2)560X470X650MM |
01) Cutting Range At 90degree: round 70mm , square 70x70mm, rectangle 95x55mm
02) Cutting Range At 45degree: round 65mm, square 60x60mm, rectangle 65x55mm
03) Diameter of sawing blade: 250mm
04) Speed of sawing blade( rate/min) : 40/80
05) Motor power: 0.95/1.1KW (Two speed motor)
06) N.W.: 85Kgs
07) Packing size: (1)1030X570X760MM, (2)560X470X650MM
CUTTING BLADE SUPPLIED AS OPTIONAL
