| Prod Model: |
DCB series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Drilling Diameter: |
800mm |
| Max. Drilling Depth: |
15m |
| Type: |
Multifunction Pile Driver |
Product Description
pile drivers, driving piles, foundation piles, pile equipment, pile driving equipment
Multifunction Pile Driver was developed by Xuzhou Hercules Machine Manufacture Co., Ltd. It is an innovative piling leader based on the other piling drivers advantages and the consideration of construction site demand. The body frame of this kind of Multifunction Pile Drive is adopted the Diesel Hammer's frame structure which has the highly rigidity. Equipped with special electricity, operation and hydraulic system, this machine could suit to different construction engineering needs. with smaller land loading pressure and exceptionally stable in different working situations, the machine could be fitted with optional pile driving equipments for Drilling Rig, Precast Pile, Gravel Pile, Diesel Hammer, Rammed Pedestal Pipe and so on.
Products Features:
1. The hydraulic rotation is flexible and could rotate 360° . So it can press a dead and corner pile.
2. Low noise, low vibration, no pollution and shock less when using as CFG Plies.
3. Incorporated machine, electricity and hydraulic into a whole, this machine has an ascendant quality-to-price.
4. The four leg-supported cylinders are designed to load or unload automatic, which makes it is not only convenient for long-distance transportation, but also increase the overall stability of construction.
5. This kind of Foot-step Multifunction Pile Driver has been proven productivity due to excellent mobility, easy and fast operating and top pile driving performance.
6. Two Traveling Motion: Foot-step and Crawler.
| Technical Data | Model |
| DCB60 | DCB80 | DCB60L | DCB80L |
| Max Vibratory Hammer Model | DD63/TD50/DZ75KS | DD83/TD62/DZ90KS | DD63/TD50/DZ75KS | DD83/TD62/DZ90KS |
| Max. Drilling Diameter (mm) | 600 | 800 | 600 | 800 |
| Max. Drilling Depth (m) | 15 | 15 | 15 | 15 |
Main
Winch | Line Pull (T) | 5 | 8 | 5 | 8 |
| Line Speed (m/min) | 18 | 18 | 18 | 18 |
Auxiliary
Winch | Line Pull (T) | 5 | 5 | 5 | 5 |
| Line Speed (m/min) | 20 | 20 | 20 | 20 |
| Rotary Drive Power (KW) | 2x45 | 2x55 | 2x45 | 2x55 |
| TravelingMotion | Hydraulic Foot-step | Hydraulic Foot-step | Electric Crawler | Electric Crawler |
| Max. Gradient of Groundwork | 2 o | 2 o | 2 o | 2 o |
| Rotation Angle | 360 o | 360 o | 360 o | 360 o |
Overall
Dimension | working condition | 13x5.3x25m | 13x5.3x25m | 13x5.3x25m | 13x5.3x25m |
| transportation condition | 15.8x2.5x3.38m | 15.8x2.5x3.38m | 15.8x2.5x3.38m | 15.8x2.5x3.38m |
| Overall Weight (T) | 40 | 50 | 45 | 50 |
Xuzhou Hercules Machine Manufacture Co., Ltd. is ISO9001 quality management system certification enterprise, the certified supplier by SGS, the high-tech private enterprise in Jiangsu province, Jiangsu province AAA grade Credit enterprise; Jiangsu province AAA grade Quality, Integrity Services enterprise and the company also was "Xuzhou Piling Machinery (Hercules) Engineering Research Centers".
Hercules piling machinery was awarded the title of Jiangsu High-tech Products. Our company has 20 state grade patents and new practical patents. Our machine had become the new benchmark for quality piling machinery!
Our main products include Long Auger Drilling Rigs (drilling diameter: Φ 300-Φ 1500mm, drilling Depth: 10m-35m), Diesel Hammer Pile Drivers (4T-10T), Rail Type and Electric Crawler Wick Drain Drivers, Percussion Drilling Rigs (drilling diameter: Φ 800-Φ 3000mm). Especially the machine Multi-function Pile Drivers integrated with expansion pile, compaction pile, gravel pile, pilling rig and prefabricated pipe pile, which favored by the users and lead the sale. We can also make the machinery and the components according to the customers' Requirement.
With the characters of first-class R & D team, controlling the overall design, pursuit of the details, continuously improving according to the users' Experience and lesson in practical engineering, especially the strengthening processing for the key parts, our machines ensure to afford higher-intensity operations and meet user higher efficient construction requirements.
Hercules always believes that the interests of customers are more than our own interests which is also the standard for you to trust us. Hercules treasures your trust and confidence and we always begin from maintaining your construction efficiency.
